SCBA Standards & Specifications

SCBA Compressed Air Specifications

Trace Analytics, LLC specializes in the analysis of thousands of compressed breathing air samples each year.

Our scientifically designed compressed air testing kits make collection a simple task. Keep the small, portable kit, and return the lightweight sample via the shipping method of your choice.

Selected SCBA Compressed Breathing Air Specifications are shown below. If the specification you need is not shown, please Contact Us. We have many more air & gas specifications in our database. If you need a custom specification, Contact Us with your requirements.

More Specifications Info

Need a Custom Spec?

Download Custom Spec Sheet here

SCBA USE - SELECTED AIR QUALITY SPECIFICATIONS
AIR QUALITY SPECIFICATION THC CO CH4 CO2 H2O DP, °F O2 N2 OIL ODOR
CGA Grade D (G-7.1-2011) N/A 10 N/A 1000 67 -50 19.5-23.5 N/A 5 None/Slight
CGA Grade L (G-7.1-2011) (SCBA) N/A 10 N/A 1000 24 -65 19.5-23.5 N/A 5 None/Slight
NFPA 1989-2013 (N) 25 (T) 5 N/A 1000 24 -65 19.5-23.5 75.0-81.0 2 Not Pronounced
OSHA 1910.134 Respiratory Protection - 2004 Cylinder (Y) N/A 10 N/A 1000 67 -50 19.5-23.5 N/A 5 None/Slight
OSHA 1910.134 Respiratory Protection - 2004 SCBA (S) N/A 10 N/A 1000 67 -50 19.5-23.5 N/A 5 None/Slight
THC = Total Gaseous Hydrocarbons, ppmv
CO2 = Carbon Dioxide, ppmv
O2 = Oxygen, volume %
HS = Halogenated Solvents, ppmv
CO = Carbon Monoxide, ppmv
H2O = Water, ppmv
N2 = Nitrogen, volume %
Odor = Odor as supplied by customer
CH4 = Methane, ppmv
DP = Dew Point, °F at 0 psig
Oil = Oil Mist & Particulate, mg/m3
Air & Gas Specifications referenced above may be viewed and/or purchased from:

CGA - Compressed Gas Association NFPA - National Fire Protection Association OSHA - Occupational Health & Safety Administration
