Airline Respirator Standards & Specs

Compressed Air Specifications

Trace Analytics, LLC specializes in the analysis of thousands of compressed breathing air samples each year. Many of our customers have established their own criteria by monitoring the performance of the system over a given time period, reviewing literature/specifications, evaluating equipment parameters, and determining company objectives.

Our scientifically designed compressed air testing kits make collection a simple task. Keep the small, portable kit, and return the lightweight sample via the shipping method of your choice.

The following are some commonly used Airline Respirator Compressed Breathing Air Specifications. If the specification you need is not listed below, please Contact Us. We have many more air & gas specifications in our database. If you need a custom specification, Contact Us with your requirements.

More Specifications Info

Need a Custom Spec?

Download Custom Spec Sheet here

AIRLINE RESPIRATORS - SELECTED AIR QUALITY SPECIFICATIONS
AIR QUALITY SPECIFICATION THC CO CH4 CO2 H2O DP, °F O2 N2 OIL ODOR OTHER
CGA G-7-2011 Grade D (1) N/A 10 N/A 1000 N/A N/A 19.5-23.5 N/A 5 None/Slight N/A
CGA G-7-2011 Grade D (2) N/A 10 N/A 1000 N/A N/A 19.5-23.5 N/A 5 None/Slight N/A
CGA G-7.1-2011 Grades D & E (2) 25 10 N/A 1000 N/A N/A 20-22 N/A 5 None/Slight N/A
CSA Z180.1-2013 (<15 psig)(N) N/A 5 10 600 N/A N/A 20-22 N/A 1 None/Slight Halogenated Hydrocarbons, ppmv
5
CSA Z180.1-2013 (15-2216 psig)(L) N/A 5 10 600 N/A N/A 20-22 N/A 1 None/Slight Halogenated Hydrocarbons, ppmv Pressure Dewpoint, °C
5 Subtract 5°C from Lowest Temp; Use -5°C as Default
OSHA 1910.134 Respiratory Protection-2004 Compressor (O) N/A 10 N/A 1000 (O) (O) 19.5-23.5 N/A 5 None/Slight N/A
THC = Total Gaseous Hydrocarbons, ppmv
CO2 = Carbon Dioxide, ppmv
O2 = Oxygen, volume %
HS = Halogenated Solvents, ppmv
CO = Carbon Monoxide, ppmv
H2O = Water, ppmv
N2 = Nitrogen, volume %
Odor = Odor as supplied by customer
CH4 = Methane, ppmv
DP = Dew Point, °F at 0 psig
Oil = Oil Mist & Particulate, mg/m3
Air & Gas Specifications referenced above may be viewed and/or purchased from:

CGA - Compressed Gas Association CSA - Canadian Standards Association OSHA - Occupational Health & Safety Administration
